Home Lab Infrastructure: england.local
This website serves as the central documentation and configuration management for my home lab. It covers the deployment of a segmented network supporting secure remote access, redundant DNS/DHCP, multi-tier storage, and specialized database services. There is also a live view of the servers with the
Network Topology Overview
The infrastructure is built on a hierarchical model focused on high availability and secure perimeter management.
1. Perimeter & Gateway
-
cisco.firewall.england
Role: Network Gateway / Edge Firewall.Manages the external-to-internal boundary, handling NAT, firewall rules, and initial traffic shaping for the entire `england.local` domain.
-
vpn.server.england
Role: Remote Access Gateway.Provides secure internal network connectivity via OpenVPN. It also hosts a custom Java-based authentication server (WolAuthServer) for on-demand hardware wake-ups.
2. Core Network Services
-
network.england
Role: Primary DNS & DHCP.Centralized authority for local hostname resolution and IP address management (DHCP) for all lab clients and servers.
-
file.extension.england
Role: Network Redundancy & Security.Operates as the Secondary DNS and a Pi-hole instance for network-wide ad-blocking. Additionally provides off-site backup parity for the primary storage array.
3. Data & Application Layers
-
file.server.england
Role: Primary Storage Array.Hosts 6.5TB of hybrid ZFS/HDD storage for centralized media and project data, accessible via SMB/NFS and iSCSI protocols.
-
database.server.england
Role: Encryption Software Backend.Dedicated MariaDB host optimized for a proprietary file encryption software suite, featuring automated cloud-sync and custom heartbeat orchestration.
Technical Specifications: Primary Workstation
- traes-pc
- OS: Pika OS (Linux) running X11.
- Hardware: AMD Ryzen 9 9950X3D | 32GB DDR5-6000 | NVIDIA RTX 5060 Ti (16GB).
- Function: Primary development environment and management console for the `england.local` network.
Maintenance & Automation Logic
The lab utilizes a "Pull" documentation model. Audit scripts running on individual nodes push their current configuration states to this repository. This ensures that documentation remains an accurate reflection of the live environment, capturing:
- Active systemd services and units (Linux) and rc.d (BSD).
- Cron-based maintenance and power-state schedules.
- Network port listening states and service dependencies.
